14 June, 2002
ADF/SCANNER SECT
IONS
3-5
Replacement
Adjustm
ent
3.2.3
REPLACING THE REVERSE ROLLE
R
A
ND TORQUE
LIMITER (P
A
RT OF THE
A
DF M
AINTENANCE KIT)
1.
Remove th
e separatio
n roller cover [A].
2.
Remove th
e clip [B] an
d replace the r
everse rol
ler [C] and tor
que limiter [D
].
NOTE:
If you install al
l parts in the ADF m
aintenance kit at t
he same time,
be sure
to reset the PM
counter (ADF)
.
H310R050.
W
MF
H310R051.
W
MF
[A]
[B]
[C]
[D]
34
36
