Rinstrum R320 Reference Manual

Reference Manual V1.19 Software Versions 4.xx
Page 56 003R-682-119
14. Setpoints – K356
The instrument is capable of working with two advanced internal setpoints. The status of these
setpoints is displayed on the LCD. Each setpoint are associated with a physical output driver but it
may also be simply used as an indicator.
14.1. Setpoint Menu Setup - SET.PTS (K356)
TARG.1
(Target for Output 1)
This is the target value for output 1. This target provides the threshold
value when the OVER or UNDER type options are selected.
Range: –99999 to 999999
Default: 000000
SETPT.1
(Output 1 Type)
The type of output control associated with output 1.
Options:
OFF: The output is disabled (turned off).
ON: The output is enabled (turned on).
OVER: The output is turned on when the source weight is over the
target value and turned off otherwise.
UNDER: The output is turned on when the source weight is under the
target value and turned off otherwise.
MOTION: The output will be driven whenever weight motion is detected.
ZERO: The output will be driven whenever the weight motion is within
the zero deadband.
NET: The output will be driven whenever net weight is displayed.
ERROR: The output will be driven whenever there is a diagnostic error.
Default: OFF
SRC.1
(Weight Source for
Output 1)
The weight source determines the weight reading that is used for output
1 comparisons.
Options:
GROSS: Use gross weight readings always.
DISP: Use the displayed weight (gross or net).
NET: Use net weight readings always.
Default: GROSS
ALARM.1
(Alarm for Setpoint 1)
An alarm is triggered when setpoint 1 is active.
Options:
NONE: no alarm
FLASH: flash display
DOUBLE: double BEEP
SINGLE: single BEEP
Default: NONE
HYS.1 (Hysteresis 1)
Hysteresis defines the amount of weight required for an active set point
to become inactive again. HYS.1 is the hysteresis for set point 1. A
value of 0 still allows for 0.5 graduations of hysteresis.
Range: 0 to 999999
Default: 0
TARG.2
(Target for Output 2)
This is the target value for output 2. This target provides the threshold
value when the OVER or UNDER type options are selected.
Range: –99999 to 999999
