2-6
FlexPak 3000 DC Drive OIM User’s Guide
2.2.1 Drive Status Indicators
The indicators on the right of the display allow you to check the status of the drive. In
figure 2.2, the Interlock OK and Drive Ready indicators are shown on. The indicators
are described in table 2.3.
2.2.2 Key Indicators
There are five indicators at the bottom of the screen above the keys. When is
set to
KEYPAD
, these indicators tell you which setting is selected by the key. If one of
the other control sources is selected, these indicators tell you the setting selected by
that control source.
Table 2.3 – Drive Status Indicators
Indicator State Description
Fault On At least one fault has occurred. See chapter 7 for fault information.
Off There are no faults.
Alarm On At least one alarm has occurred. See chapter 7 for alarm information.
Off There are no alarms.
Interlock OK On The coast/DB contact and all customer interlocks (Regulator board terminal 9) are
closed. See the hardware manual for more information.
Off One or more customer interlocks or the coast/DB contact is open.
Drive Ready On Drive is ready to run or jog. All customer interlocks are closed, the coast/DB
contact is closed, and there are no faults.
Off Drive is not ready. See chapter 7 for diagnostics information.
Running On The contactor is closed and the motor armature is energized in either run or jog
mode. The drive is running.
Off The contactor is open and the drive is not running.
Current Limit
Torque Limit
On Drive is operating at the maximum allowable current or torque.
Off Drive is not at the maximum allowable current or torque.
