3-4
FlexPak 3000 DC Drive OIM User’s Guide
3.4 Scaling Values Displayed on the OIM
If needed, you can scale speed, load, and outer control loop units to match your
application requirements. You can select from pre-defined units, or configure your own
units through the
OTHER
option. (
OTHER
is available only for speed and outer control
loop units.) Scaling these units affects only the
OIM
display.
If you do not change these values, they are set to the defaults of:
•
RPM
for speed units
•
%
FLA
for load units
•
% for outer control loop units
The scaling options are:
•
Speed units:
RPM
, %, or
OTHER
•
Load units: %
FLA
or
AMPS
•
Outer control loop units:
AMPS
, %, or
OTHER
User units affect the monitor mode displays, including display of the serial and keypad
references and the parameters listed in table 3.1.
Table 3.1 – Parameter Displays That are Affected by Scaled Units
Parameter Displays Affected by Speed Units
ANALOG AUTO REFERENCE
(P.188)
PRESET SPEED
2 (P.118)
ANALOG MAN REFERENCE
(P.192)
PRESET SPEED
3 (P.119)
ANALOG MAN TRIM REF
(P.194)
PULSE TACH FEEDBACK
(P.292)
ANALOG TACH FEEDBACK
(P.291)
SPD LOOP ERROR
(P.297)
CURRENT COMPOUND TP
(P.293)
SPD LOOP FEEDBACK
(P.296)
JOG RAMP OUTPUT
(P.294)
SPD LOOP LAG OUTPUT
(P.298)
JOG SPEED
(P.012)
SPD LOOP REFERENCE
(P.295)
MAXIMUM SPEED
(P.004)
SPD SOURCE SELECT OUT
(P.193)
MINIMUM SPEED
(P.003)
SPEED RAMP INPUT TP
(P.198)
MOP OUTPUT
(P.191)
SPEED RAMP OUTPUT
(P.199)
OCL OUTPUT
(P.848)
STOP SPEED THRESHOLD
(P.113)
PRESET SPEED
1 (P.117)
TRIM OUTPUT
(P.197)
Parameters Affected by Outer Control Loop Units
OCL FEEDBACK
(P.847)
OCL REFERENCE
(P.845)
OCL RAMP OUTPUT
(P.846)
OCL REF REGISTER
(P.801)
Parameter Displays Affected by Load Units
CML ERROR
(P.398)
SPD LOOP OUTPUT
(P.299)
CML FEEDBACK
(P.397)
TORQUE REFERENCE
(P.189)
CML REFERENCE
(P.396)
