Description of the OIM Keypad, Display, and Indicators
2-7
In figure 2.2, the keys are set to
PROGRAM
,
KEYPAD
,
MANUAL
, and
FORWARD
. Indicators
are described in table 2.4.
Table 2.4 – Key Indicators
Key Indicator Above
Possible
Indications Description
PROGRAM OIM
is in program mode.
MONITOR OIM
is in monitor mode.
(blank)
OIM
is in a fault, alarm, or diagnostic menu.
FAULT
Fault Menu is displayed.
ALARM
Alarm Menu is displayed.
DIAGS
Diagnostics Menu is displayed.
TERMBLK
Signals at the Regulator board terminal strip control the drive.
NETWORK
A network is controlling drive operation. Blinks when network
communication is not active.
SERIAL
Drive is controlled through its serial port, typically by the
CS3000 software.
KEYPAD OIM
keys control drive operation.
AUTO
or
MANUAL
Depends on the setting of . See section 6.2.
FORWARD
The drive is configured to run the motor in the forward
direction.
REVERSE
The drive is configured to run the motor in the reverse
direction.
