2-8
FlexPak 3000 DC Drive OIM User’s Guide
2.2.3 Special Display Characters
There are several special characters you might see on the display. They are described
in table 2.5.
Table 2.5 – Special Display Characters
or
]
The cursor. Indicates the currently selected options. Use
and to move the cursor. Use and to
move the
]
cursor.
▲ Displayed if more text or options are available above the
top selection. Press to view the information.
▼ Displayed if more text or options are available below the top
selection. Press to view the information.
Locked cursor. Displayed instead of if a menu or
parameter option is not available.
