Troubleshooting the Drive Using the OIM
7-9
7.7 Resetting the Clock
The elapsed time clock on the drive displays the day and time since the last power
cycle or clock reset. The time is based on an internal 248-day counter.
The clock is primarily used to show when a fault or alarm occurred. It is reset by
cycling power or by using the procedure described here.
To reset the clock:
Step 1. Press
until the key indicator reads
PROGRAM
.
Step 2. Press or until the cursor ( ) is pointing to Operator Interface.
Press
.
Step 3. Press or until the cursor is pointing to Reset Clock. Press .
Step 4. The
OIM
resets the elapsed time clock to 000 days 00 hours 00 mins 00 secs
and displays the message shown in figure 7.9. Press to return to the
menu.
Figure 7.9 – Reset Clock Message Screen
