Roland MC-808 User Manual

94
Editing rhythm sounds (Rhythm Edit)
Rhythm editing parameters
SYNTHESIZER 1
SYNTHESIZER 2
For details on each parameter, refer to “Rhythm editing parameters” (p. 57) in “Sound & Parameter List.”
The LFO and MATRIX CONTROL parameters don’t apply to the rhythm part.
The patches of the MC-808 contain many other parameters in addition to those listed here.
You can use the dedicated editor that’s included to edit these additional parameters.
For details on how to install and use the editor, refer to “Using MC-808 editor” (p. 137).
[PART ASSIGN]=OFF
[PART ASSIGN]=ON
Fader Indication Range Indication Range
1
Cutoff 0–127 Pitch Env Depth -12–+12
2 Resonance 0–127
* Depends on the Resonance
Limiter setting (p. 121).
Pitch Env Attack (Time1)
0–127
3 Filter Type OFF, LPF, BPF, HPF, PKG,
LPF2, LPF3
Pitch Env Decay (Time3) 0–127
4 LFO1 Waveform – Filter Env Depth -63–+63
5 LFO1 Pitch Depth – Filter Env Attack (Time1) 0–127
6 LFO1 Filter Depth – Filter Env Decay (Time3) 0–127
7 LFO1 Amp Depth – Filter Env Sustain (Level3) 0–127
8 LFO1 Rate – Filter Env Release (Time4) 0–127
[PART ASSIGN]=OFF
[PART ASSIGN]=ON
Fader Indication Range Indication Range
1
Amp Env Attack (Time1) 0–127 Amp Level 0–127
2 Amp Env Release ( Time4 ) 0–127 Amp Env Attack (Time1) 0–127
3 Fine Tune -50–+50 Amp Env Decay (Time3) 0–127
4 Matrix Control – Amp Env Sustain (Level3) 0–127
5 MFX1 C1 For details, refer to “Ap-
plying effects, “Mastering
effect” (p. 64).
Amp Env Release (Time4) 0–127
6 MFX1 C2 Random Modify 0–127
7 MFX2 C1 Reverb Time (C1) 0–127
8 MFX2 C2 Reverb Level (C2) 0–127
