1-2. Major Component Specifi cations
(B) Outdoor Units
SPW-C256VH
MODEL No.
SPW-C256VH
Source
220-230-240V, 1 phase, 50/60Hz
Controller P.C.B. Ass'y
CR-C256VH (Microprocessor)
Control circuit fuse 250V, 25A
Compressor
Model....number C-6RVN103H0S
Source 124V (DC) / 3phase / 60Hz (Inverter drive)
Nominal output W 1,500
Compressor oil cc 600
Coil resistance
(Ambient temperature 25°C)
Ω
C – R : 0.452 R – S : 0.452
C – S : 0.452
Safety control
Overload relay models Excessive current control, Discharge temperature control
Operation temperature
Open °C –
Close °C –
Crank case heater –
Refrigerant amount at shipment
kg R410A - 1.7
High pressure switch
–
Set pressure
OFF kg / cm
2
–
ON kg / cm
2
–
Fan
Number...diameter mm 1...ø420
Air circulation m
3
/ h 2,220
Fan speeds (Max.)
~1,000 rpm (Inverter drive control)
Fan motor
Model No. DAJ12-55Q71-CR
Source ~280V / 3 phase
No. of pole 8
Nominal output W 60
Heat exchanger
Coil Aluminium plate fin / Copper tube
Rows...fin pitch mm 2...1.3
Face area m
2
0.452
