Sanyo SPW-U485H User Manual

1
1-307
TP6 TP3 TP1
TP6 TP3 TP1
Item
code
No. Description
0000 Standard (setting at shipment)
0003 High static-pressure
Indoor control board
External Static Pressure (Pa)
Air ow (m
3
/minute)
External Static Pressure (Pa)
Air ow (m
3
/minute)
External Static Pressure (Pa)
Air ow (m
3
/minute)
External static pressure’s
upper limit high static
pressure mode
Rated external static
pressure in high static
pressure mode
Lower static pressure
in high static pressure
mode
Rated external static
pressure at shipment
Lower limit air ow
Standard external
static pressure’s
upper limit
Upper limit air ow
External Static Pressure (Pa)
Air ow (m
3
/minute)
For Short Circuit Connection
• The standard (before shipment) external static pressure is shown in the table below.
• When using with a higher static pressure, it is necessary to change to the high static pressure mode.
For Wired Remote Control
Press and hold the , and buttons simultaneously for 4
seconds or longer.
“ , ” unit No.” ” (or “ ” in the case of group control),
item code “
, ” and settings data “ ” are displayed
blinking on the remote controller LCD display.
At this time, the indoor unit fan (or all indoor unit fans in the case
of group control) begins operating.
Press the temperature setting / buttons to select
the item code “
”.
Press the timer time / buttons to select the desired
setting data.
* For item codes and setting data, refer to the right table.
Press the button.
(The display stops blinking and remains lit, and setting is
completed.)
Press the button to return to normal remote controller display.
External static pressure 125 / 165 / 185
Standard 15
High static pressure 40
When using with high static pressure mode, set the indoor unit
control board as shown at right.
Follow the below procedure while the unit is turned off.
(1) Open the cover of the electrical box and con rm that it is the
indoor unit control board.
(2) Connect the short circuit connector to the short circuit pin TP3
(2P: Yellow) of the indoor unit control board.
• In case of wired remote control setting, do not use the short
circuit connector.
White Yellow Red
6
1
5 1
4
3
2
L
H
H
HH
L
HH
456789101112 5 6 7 8 9 10 11 12 13 7 8 9 101112131415
SPW-US185HSPW-US165HSPW-US125H
(mmAq)
0
H
L
10
20
30
40
50
0
10
20
30
40
50
60
0
10
20
30
40
50
60
0
5
(mmAq)
0
5
(mmAq)
0
5
H
L
L
H
L
H
L
H
HH
HH
H
L
HH
HT
HH
HH
HH
SM830160-03ClassicPAC-iA4.ind307307SM830160-03ClassicPAC-iA4.ind307307 2010/02/1610:26:452010/02/1610:26:45
