Simultaneous(Twin)-Type
1-1. Unit Specifi cations
4-Way Air Discharge Semi-Concealed Type SPW-XDR124GH56 (A/B) x2 / SPW-C256VH
MODEL No.
Indoor Unit SPW-XDR124GH56 (A/B) x2
Outdoor Unit SPW-C256VH
POWER SOURCE
220 - 230 - 240 V, 1 phase, 50/60 Hz
PERFORMANCE
Cooling Heating
Capacity [min~max]
kW 7.1 [2.2~8.0] 8.0 [2.2~9.0]
BTU / h 24,000 [7,500~27,000] 27,000 [7,500~30,000]
Air circulation (Hi / Me / Lo) m
3
/ h 1,860 / 1,680 / 1,560 (930 / 840 / 780 x2)
Moisture removal (High) Liters / h 4.4 (2.2 x2) –
ELECTRICAL RATINGS
Voltage ratings V 220 230 240 220 230 240
Available voltage range V 198 - 264 198 - 264
Running amperes* A 11.5 11.2 10.8 12.3 11.9 11.5
Max–Running amperes** A – – – – – –
Power input kW 2.21 2.21 2.21 2.35 2.35 2.35
C.O.P W / W 3.21 3.21 3.21 3.40 3.40 3.40
Max.Starting amperes A – – – – – –
FEATURES
Controls / Thermostat control Microprocessor / I.C.thermostat
Timer ON / OFF 72-hours
Fan speeds Indoor / Outdoor 3 and Automatic control / Variable
Airflow direction (Indoor) Automatic (Remote control)
Air filter Washable, easy access, long life (2,500 hr)
Remote controller (Option) Wired: RCS-TM80BG Wireless: RCS-SH80BG.WL
Refrigerant control –
Drain pump (Drain connection) Max.head 64cm above drain connection (25A, OD32mm)
Compressor Rotary (SANYO)
Operation sound
Indoor - Hi / Me / Lo dB-A 31 / 29 / 27
Outdoor - Hi dB-A 48 50
Color
(Approximate value)
Indoor Munsell 2.5GY 9.0 / 0.5
Outdoor Munsell 1Y 8.5 / 0.5
REFRIGERANT TUBING
Indoor unit Outdoor unit
Limit of tubing length m (ft.) 50 (164)
Limit of tubing length at shipment m (ft.) 3~20(10~65)
Limit of elevation difference
between the two units
m (ft.)
Outdoor unit is higher than indoor unit: 30 (98)
Outdoor unit is lower than indoor unit: 15 (49)
Refrigerant tube
outer diameter
Liquid tube mm (in.) 6.35 (1 / 4) 9.52 (3 / 8)
Gas tube mm (in.) 12.7 (1 / 2) 15.88 (5 / 8)
Refrigerant amount at shipment kg – R410A - 1.7
DIMENSIONS & WEIGHT
Indoor unit (include panel) Outdoor unit
Unit dimensions
Height mm (in.) 291 (11-15 / 32) 569 (22-13 / 32)
Width mm (in.) 950 (37-13 / 32) 790 (31-7 / 64)
Depth mm (in.) 950 (37-13 / 32) 285 (11-7 / 32)
Package dimensions
Body Panel Outdoor unit
Height mm (in.) 283 (11-5 / 32) 104 (4-3 / 32) 645 (25-25 / 64)
Width mm (in.) 892 (35-4 / 32) 1008 (39-22 / 32) 921 (36-17 / 64)
Depth mm (in.) 905 (35-20 / 32) 990 (38-31 / 32) 285 (11-7 / 32)
Net weight kg (lb.) 25.5 (56) 41 (90.5)
Shipping weight kg (lb.) 24 (53) 7 (16) 45.5 (100.3)
Shipping volume m
3
(cu.ft) 0.228 (8.1) 0.104 (3.8) 0.169 (5.98)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Cooling:
Rating conditions (*): Indoor air temperature 27°C DB/19°C WB, Outdoor air temperature 35°C DB
Full load conditions (**): Indoor air temperature 32°C DB/23°C WB, Outdoor air temperature 43°C DB
Heating:
Rating conditions (*): Indoor air temperature 20°C DB, Outdoor air temperature 7°C DB/6°C WB
Full load conditions (**): Indoor air temperature 24°C DB, Outdoor air temperature 24°C DB/15.5°C WB
