SICK DME4000 User Manual

Chapter 9 Operating Instructions
DME4000
110 © SICK AG • Germany • Subject to change without notice 8014584/ZN33/2017-07
Appendix
9.2.1 Data Format Slave to Master
(DDLM_Data_Exchange)
Encoder-profile
Bit 31 ... 0
Measurement value in complement on two; unit corresponding to resolution
SICK-profile
Active (1) Not active (0)
Bit 31
Sensor error
Sensor OK
Bit 30
Measurement error
Measurement value OK
Bit 29
Pre-failure message
Sensor OK
Bit 28
Not ready to operate
Ready to operate
Bit 27
Laser off (standby)
Laser on
Bit 26
MF2 active
MF2 not active
Bit 25
MF1 active
MF1 not active
Bit 24 ... 0
Measurement value in complement on two; unit corresponding to resolution
9.2.2 Data Format Master to Slave
(DDLM_Data_Exchange)
Active (1) Not active (0)
Encoder-profile
Bit 31
Preset model
Bit 30 ... 0
Preset value in 2nd complement. Unit corresponding to resolution. Value range
+/ 250 m
SICK-profile
Active (1)
Not active (0)
Bit 31
Preset model
Bit 30
Not assigned
Not assigned
Bit 29
Laser off
Laser on
Bit 25 ... 28
Not assigned
Not assigned
Bit 24 ... 0
Preset value in 2nd complement. Unit corresponding to resolution.
Value range (also refer to the parameter data for the preset mode)
9.2.3 Diagnosis Data
(DDLM_Slave_Diag)
Encoder-profile
Diagnosis
Class 1
Octet 1 ... 16
Octet 7... 16
Class 2
Octet 1 ... 63
Octet 7... 63
