9.8.5 Store parameters in DME
Parameters, modified with SDO service, are stored non permanently. With activating CANopen-object
“Store Parameter Field” the parameters are stored permanently in the DME4000. For activation the
according sub index has to be written with “1”. See table below:
Index (Hex)
0x1010, sub index 001
Save all Parameter
0x1010, sub index 003
Save Application Parameters
The object “Save Communication Parameters” Index 0x1010, sub index 002 is not supported. This
means parameter settings in the “Communication Segment” of the object directory including TPDO-
Parameter are not stored permanently and are set to default values after device restart.
9.8.6 Additional diagnostic values
Following diagnostic values can be read with the SDO-service (SDO = Service Data Object).
Index (Hex)
Chapter for further information
0x2200
Measurement Level
-
0x2201, subindex 001
Error status “Temperature”
11
0x2201, Subindex 002
Error status “Laser”
11
0x2201, Subindex 003
Status “telegram traffic”
11
0x2201, subindex 004
Error status “Attenuation”
11
0x2201, Subindex 005
Error status “Plausibility”
11
0x2201, Subindex 006
Status “Ready”
11
0x2202
Temperature
-
0x2203
Operating Hours
-
0x2204
Speed
-
