Chapter 9 Operating Instructions
DME4000
116 © SICK AG • Germany • Subject to change without notice 8014584/ZN33/2017-07
Appendix
Function Commands
<STX><0x03>
<
0x32
>
<ETX>
Laser On (Sleep mode)
<STX><0x03><0x33><ETX>
Laser Off (Sleep mode)
<STX><0x03>
<
0x35
>
<ETX>
Preset activation
9.5.3 Command examples (Standard protocol)
Value binary request
 to DME <STX><0x01><0x21><ETX>
 from DME <STX><0x81><0x21><0x..>… <0x..><0x..><0x..><ETX>
 example terminal 5378,8 mm ⇒ 81210000D21C
(14 bytes: 02 38 31 32 31 30 30 30 30 44 32 31 43 03)
Value BCD request
 from DME <STX><0x01><0x22><ETX>
 to DME <STX><0x81><0x22><0x..>… <0x..><0x..><0x..><ETX>
 example 5378,8 mm ⇒ 8122+0053788
Value binary continuous on
 from DME <STX><0x05><0x21><0x01><ETX>
 to DME <STX><0x85><0x21><0x01><ETX>
 after that from DME
continuous <STX><0x03><0x21><0x..>… <0x..><0x..><0x..><ETX>
Value binary continuous off
 to DME <STX><0x05><0x21><0x00><ETX>
 from DME <STX><0x85><0x21><0x00><ETX>
BCD continuous on
 to DME <STX><0x05><0x22><0x01><ETX>
 from DME <STX><0x85><0x22><0x01><ETX>
 after that from DME
continuous <STX><0x03><0x22><0x..>… <0x..><0x..><0x..><ETX>
Value BCD continuous off
 to DME <STX><0x05><0x22><0x00><ETX>
 from DME <STX><0x85><0x22><0x00><ETX>
Temperature
 to DME <STX><0x01><0x26><ETX>
 from DME <STX><0x81><0x26><0x..><ETX>
 example internal temperature +54 °C ⇒ 812636 ⇒ 0x36 = 54
Reception level
 to DME <STX><0x01><0x23><ETX>
 from DME <STX><0x81><0x23><0x..><ETX>
 example -39 dB ⇒ 8123D9 ⇒ 0x100 − 0xD9 = 0x27 =39
Service-status
 to DME <STX><0x01><0x23><ETX>
 from DME <STX><0x81><0x23><0x..><ETX>
 example Icon MF2 and icon PLB is visible on the display:
812542 ⇒ 0x42 = 10000010 binär
MF2
MF1
TMP
LSR
BUS
ATT
PLB
RDY
1
0
0
0
0
0
1
0
