LMV Series Technical Instructions
Document No. LV3-1000
SCC Inc. Page 7 Section 1
Air Damper Assembly (continued)
When retrofitting a Cleaver Brooks boiler, the following kit is available for the rotary air
damper. No additional couplings are needed with this retrofit kit. Refer to Document No.
CPBK-4000 for technical information or Document No. CPBK-4100 for installation instructions.
BR-3345CBAIR
Bracket for mounting an SQM33… actuator to a
Cleaver Brooks rotary air damper
When using a Lucoma air damper, the following actuator mounting kit is available. No
additional couplings are needed with this mounting kit. Refer to Document No. CPBK-3000 for
technical information or Document No. CPBK-3100 for installation instructions.
BR-SQM3345-
LUC
Bracket for mounting an SQM33… actuator to an
8x8 through 28x28 Lucoma air damper
