Siemens LMV3 series User Manual

LMV Series Technical Instructions
Document No. LV3-1000
SCC Inc. Page 11 Section 7
Modbus Address / LMV3 Parameter Cross-Reference Guide
Modbus
Address
Description LMV3 Parameter
0
Burner control phase
961
1
Position of current fuel actuator
922:00
4
Position of air
actuator
922:01
8
Manipulated variable VSD
936
9
Current type of fuel
945
10
Current output
903:00, 903:01
13
Flame signal
954
14
Current fuel throughput
960
21
Startup counter total
166
25
Current error: Error code
701:01, 981
26
Current
error: Diagnostic code
701:02, 982
27
Current error: Error class
701:03
28
Current error: Error phase
701:04
35
Inputs
947:00
37
Outputs
947:01
38
Program stop
208
41
Modbus mode: local / remote
N/A
42
Modbus breakdown time
142
43
Modbus:
operating mode in remote
N/A
45
Preselected target output
121
56
Hours run fuel 0 resettable
162
58
Hours run fuel 1 resettable
172
68
Hours run unit live
163
70
Startup counter fuel 0 resettable
164
72
Startup counter fuel 1 resettable
174
76
Startup counter total (not resettable)
166
78
Fuel volume fuel 0
167
80
Fuel volume fuel 1
177
82
Number of faults
161
84
Preselected output no comm. (fuel 0)
148
85
Preselected output no comm. (fuel 1)
149
98
Burner control type reference (ASN)
111
106
Burner control parameter set code
104
107
Burner control parameter set version
105
108
Burner control identification date
102
111
Burner control identification number
103
113
Software version burner control
107
115
Burner identification
113
123
Minimum output fuel 0
545
124
Maximum output fuel 0
546
