Description of the device
4.5 Components of the product
SCALANCE X-300
100 Operating Instructions, 02/2012, A5E01113043-12
4.5.7 Components of the XR-324-4M PoE product
Components of the product
The following parts ship with a SCALANCE XR-324-4M PoE:
● Device with C-PLUG exchangeable medium
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
installation
● Connecting cable for the diagnostics port
● Operating Instructions (compact)
● Product CD with documentation and software
● For devices with a 100 to 240 VAC power supply:
– A 2-pin terminal block for the power supply
– A 2-pin terminal block for the signaling contact
● With devices with 24 V DC power supply:
– 4-pin terminal block for the power supply
– 2-pin terminal block for the signaling contact
– 4 adhesive feet for desktop mounting
4.5.8 Components shipped with the MM900 product
The following components are supplied with a SCALANCE MM900 media module:
● MM99x-2xx media module
● Operating Instructions (compact)
Note
Identification labels
The location labels identify the media modules and ship with the SCALANCE device.
