Description of the device
4.2 Product groups
SCALANCE X-300
76 Operating Instructions, 02/2012, A5E01113043-12
4.2.8.1 MM992-2M12 product characteristics
Possible attachments
The MM992-2M12 media module has the following:
● 2 x 10/100/1000 Mbps, GE M12 connector electrical
Figure 4-27 MM992-2M12C [9922HA]
[Device labeling in square brackets]
Note
Only the media module MM992-2SFP may be fitted with approved SFP transceivers. The
SFP media module can be fitted with up to two SFPs.
Possible attachments
The MM992-2SFP media module has the following:
● 2 x 100/1000 Mbps, SFP slot
Figure 4-28 MM992-2SFP [9922AS]
[Device labeling in square brackets]
