Installation
5.1 Overview of the methods of installation
SCALANCE X-300
104 Operating Instructions, 02/2012, A5E01113043-12
Minimum clearances
If you install the IE Switch X-300EEC in enclosures without forced ventilation or cooling,
minimum clearances must be maintained to neighboring devices or the wall of the enclosure.
By keeping to the minimum clearances, there is then an adequate stream of air for heat
dissipation during operation. Keep to the following minimum clearances to neighboring
devices.
Table 5- 1 Minimum clearances when installing the X-300EEC
Minimum clearance to devices below the switch 100 mm
Minimum clearance to devices above the switch 100 mm
Minimum clearance at the sides 20 mm
5.1 Overview of the methods of installation
Installing the switches
IE Switches X-300 can be installed in various ways:
● Installation on a 35 mm DIN rail
● Installation on a SIMATIC S7-300 standard rail
● Wall mounting
● 19" rack mounting (SCALANCE XR300)
For the possible types of installation, refer to section Technical specifications (Page 153)
Note
Standard rail and wall mounting of the IE Switch X-300EEC
With the X-300EEC, note the special features in the relevant subsection on standard rail or
wall mounting.
Media modules and SFP transceivers
Media modules and SFP transceivers are used in modular devices.
● Media modules are used in the appropriate slots of the switch.
● SFP transceivers are used only in SFP media modules.
