Approvals, certificates, standards
9.2 Product group X-300M
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
229
9.1.6 X-300 mechanical stability (in operation)
IEC 60068-2-6 vibration IEC 60068-2-27 shock Type
5 – 9 Hz: 3.5 mm
9 – 150 Hz: 1 g
1 octave/min, 20 sweeps
15 g, 11 ms duration
6 shocks per axis
X304-2FE ● ●
X306-1LD FE ● ●
X307-3 ● ●
X307-3LD ● ●
X308-2 ● ●
X308-2LD ● ●
X308-2LH ● ●
X308-2LH+ ● ●
X310 ● ●
X310FE ● ●
X320-1FE ● ●
X320-3LD FE ● ●
9.2 Product group X-300M
9.2.1 X-300M approvals, certificates
Note
The specified approvals apply only when the corresponding mark is printed on the product.
You can check which of the following approvals have been granted for your product by the
markings on the type plate.
EC directives
SIMATIC NET products meet the requirements and aims of the following EC directives.
