Installation
5.3 Inserting media modules and SFP transceivers
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
123
5.3.2 SFP installation in SFP media module
WARNING
Use only approved SFPs
If you use components not approved by Siemens AG, in particular SFPs, Siemens cannot
accept any responsibility for the correct functioning of the Ethernet switch system according
to the specification.
If components are used that have not been Siemens approved, Siemens cannot vouch for
their compatibility or for risk-free use of these components.
You can insert or remove the SFP during ongoing operation.
Inserting an SFP
NOTICE
Only the media module MM992-2SFP may be fitted with approved SFPs. The SFP media
module can be fitted with up to two SFPs.
Device:
Media module
Variant [Order number]
Labeling on the device
Figure
MM992-2SFP
(SFP media module)
2 x 100/1000 Mbps [6GK5 992-2AS00-8AA0]
9922AS
