Technical specifications
8.3 X-300M technical specifications
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
163
8.3 X-300M technical specifications
Note
Validity of the technical specifications
All the technical specifications described in this section that is not assigned to a specific
device variant, version or a media module, apply to all device variants/versions of the
product group.
8.3.1 Construction, installation and environmental conditions
Table 8- 17 Construction
Dimensions (W x H x D) 120 × 125 × 124 mm
Weight 1 400 g
Degree of protection IP20
Table 8- 18 Installation options
Installation options
• DIN rail
1)
• S7-300 standard rail
• Wall
1)
Note: When used in shipbuilding, installation on a 35 mm DIN rail is not permitted. In ships, the 35
mm DIN rail does not provide adequate support.
