8.4 XR-300M technical specifications
SCALANCE X-300
172 Operating Instructions, 02/2012, A5E01113043-12
Table 8- 40 Plug-in terminal block for connectors of the power supply and signaling contact
Device version
(power supply)
Power supply Signaling contact
2 x 24 VDC 2 x 4-pin 2 x 2-pin
1 x 100 to 240 VAC 1 x 2-pin 1 x 2-pin
8.4.3 Cable lengths
Table 8- 41 Permitted cable lengths (copper cable - Fast Ethernet)
Cable type Accessory (plug, outlet,
TP cord)
Permitted cable length
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 45 m
+ 10 m TP cord
IE TP torsion cable
with IE FC RJ-45 Plug 180 0 to 55 m
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 75 m
+ 10 m TP cord
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC RJ-45 Plug 180 0 to 85 m
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
IE FC TP standard cable
with IE FC RJ-45 Plug 180 0 to 100 m
Table 8- 42 Permitted cable lengths (copper cable - gigabit Ethernet)
Cable type Accessory (plug, outlet,
TP cord)
Permitted cable length
IE FC Standard Cable, 4 × 2, 24
AWG
IE FC Flexible Cable, 4 × 2, 24
AWG
with IE FC RJ-45 Plug 180,
4 × 2
0 to 90 m
IE FC Standard Cable, 4 × 2, 22
AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 60 m
+ 10 m TP cord
IE FC Flexible Cable, 4 × 2, 22
AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
Note
Permitted cable lengths (fiber-optic cable - Fast Ethernet or gigabit)
The values correspond to those of the permitted MM900 media modules and SFP
transceivers.
