Technical specifications
8.2 X-300 technical specifications
SCALANCE X-300
156 Operating Instructions, 02/2012, A5E01113043-12
Table 8- 3 Permitted ambient conditions
Device variant Storage/transport
temperature
Operating temperature Max. relative
humidity in
operation at 25 °C
Max. ambient
temperature at operating
altitude
X304-2FE,
X306-1LD FE,
X320-1FE,
X320-3LD FE
-40 °C to +70 °C As of hardware product
version 1:
-40 °C to +60 °C
< 95 % (no
condensation)
Max. 55 °C as of 2 000 m
Max. 50 °C as of 3 000 m
X307-3,
X308-2
-40 °C to +70 °C For hardware product
version 1:
0 °C to +60 °C
As of hardware product
version 2:
-10 °C to +60 °C
< 95 % (no
condensation)
Max. 55 °C as of 2 000 m
Max. 50 °C as of 3 000 m
X307-3LD,
X308-2LD,
X308-2LH,
X308-2LH+,
X310,
X310FE
-40 °C to +70 °C For hardware product
version 1:
0 °C to +60 °C
As of hardware product
version 2:
-40 °C to +60 °C
< 95 % (no
condensation)
Max. 55 °C as of 2 000 m
Max. 50 °C as of 3 000 m
8.2.2 Connectors and electrical data
Table 8- 4 Connection for end devices or network components
Device variant Electrical
over twisted pair
Optical
over fiber-optic cable
X304-2FE 4 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
2 x SC duplex socket (MM)
(100 Mbps, full duplex to
100BaseFX)
X306-1LD FE 6 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
1 x SC duplex socket (SM)
(100 Mbps, full duplex to
100BaseFX)
X307-3 7 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
X307-3LD 7 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
X308-2 7 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
1 x RJ-45 socket with MDI-X pinning
10/100/1000 Mbps (half/ full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
X308-2LD 7 x RJ-45 jacks with MDI-X assignment
10/100 Mbps (half / full duplex)
1 x RJ-45 jacks with MDI-X assignment
10/100/1000 Mbps (half / full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
