Accessories
4.7 Locking and interlocking
3VA molded case circuit breakers with IEC certificate
Manual, 03/2019, A5E03603177010-03
363
The following locking devices are available for 3VA molded case circuit breakers:
● Padlock device for the handle
● Cylinder locks for locking the 3VA molded case circuit breaker
Padlock device for the handle
The padlock device for the handle is directly attached to the handle of the 3VA molded case
circuit breaker and latched in place.
For installation instructions, please refer to operating instructions "Padlock device for the
handle".
When the padlock device for the handle is installed, the 3VA molded case circuit breaker can
be locked in the OFF (O) position by up to three padlocks (shackle diameter 4.5 to 8.5 mm).
