Accessories
4.8 Residual current devices
3VA molded case circuit breakers with IEC certificate
Manual, 03/2019, A5E03603177010-03
397
Side mounted residual current devices Basic RCD310 and Basic RCD510
Front view of Basic RCD310 and Basic RCD510
RCD310
Type designation
Standard
Electromagnetic release (RCR = Residual
Article number
Maximum rated operational current, rated
operational voltage and frequency
Rated insulation voltage and rated impulse
Device type
Transparent protective cover over setting
buttons
Location and date of manufacture
Setting button for response current
Only suitable for use in 3-phase systems
LED: ACTIVE and pre-alarm
Knowledge Manager
RESET button / tripped display
Contact hazard protective cover over main
current paths with sealing option
Test button (test device)
Product version
