2.6 Protection system

3VA molded case circuit breakers with IEC certificate

70 Manual, 03/2019, A5E03603177010-03

2.6.1

Description of functions

The protection function performed by the molded case circuit breaker in the power

distribution network is defined by the choice of trip unit. There are two different types of trip

unit, i.e. thermal-magnetic (TMTU) and electronic (ETU):
