Technical specifications

6.1 Circuit diagrams

3VA molded case circuit breakers with IEC certificate

548 Manual, 03/2019, A5E03603177010-03

6.1.2

3VA2 molded case circuit breakers

6.1.2.1

Basic units

Fixed mounting and plug-in/draw-out units, 3-pole and 4-pole

①

Fixed mounting, 3-pole and 4-pole

②

Plug-in/draw-out units, 3-pole and 4-pole

* Voltage tap
