Plant changes during redundant operation - H-CiR
12.10 Editing CPU parameters
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
217
9. Switch to CPU with modified configuration.
– In SIMATIC Manager, select a CPU of the fault-tolerant system, then select "PLC >
Mode" from the menu.
– In the "Mode" dialog box, click "Switch to..."
– In the "Switch" dialog box, select "with modified configuration" and click on the
"Switch" button.
– Confirm the security prompt with "OK".
10.Proceed as follows to remove an interface module from the subsystem of the original
master CPU (currently in STOP mode):
– Switch off the power supply of the standby subsystem.
– Remove an IM460 from the central unit.
or
– Remove an expansion unit from an existing line.
or
– Remove an external DP master interface module.
– Switch on the power supply of the standby subsystem again.
11.Transition to the redundant system state.
– In SIMATIC Manager, select a CPU of the fault-tolerant system, then select "PLC >
Mode" from the menu.
– In the "Mode" dialog box, select the standby CPU and click "Warm restart".
12.Change and download the user program (see Modify and download the user program
(Page 213))
Editing CPU parameters
12.10.1
Only certain CPU parameters (object properties) can be edited in operation. These are
highlighted in the screen forms by blue text. If you have set blue as the color for dialog box
text on the Windows Control Panel, the editable parameters are indicated in black
characters.
Note
If you edit any protected parameters, the system will reject any attempt to changeover to the
CPU containing those modified parameters. The event W#16#5966 is written to the
diagnostic buffer. and you will then have to restore the wrongly changed
parameters in the
parameter configuration to their last valid values.
