Siemens SIMATIC CPU 410 User Manual

Technical data
16.3 Technical specifications of the system expansion card
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
273
Article number
6ES7410-5HM08-0AB0
Dimensions
Width
50 mm
Height
290 mm
Depth
219 mm
Weights
Weight, approx.
1.1 kg
16.3
Technical specifications of the system expansion card
PCS7 System Expansion Card PO 0
Article number
6ES7653-2CH00-0XB0
General information
Product type designation
PCS 7 System Expansion Card PO 0
Hardware product version
3
Firmware version
V2.0
Design of PLC basic unit With Conformal Coating (ISA-S71.04 severity
level G1; G2; G3) and operating temperature to
70 °C
Memory
PCS 7 process objects 0; PO for CPU 410-5H; expandable by means of
CPU 410 Expansion Pack PO 100 or PO 500
Work memory
• integrated
0 Mbyte
• expandable
Yes, by means of CPU 410 Expansion Pack PO
100 or PO 500
Address area
I/O address area
• Inputs
Use of 16 KB in the CPU 410-5H
• Outputs
Use of 16 KB in the CPU 410-5H
of which distributed
– DP interface, inputs
6 kbyte; up to 2 800 IOs (channels)
– DP interface, outputs
6 kbyte; up to 2 800 IOs (channels)
– PROFINET interface, inputs
8 kbyte; up to 3 800 IOs (channels)
– PROFINET interface, outputs
8 kbyte; up to 3 800 IOs (channels)
Digital channels
• Inputs
131 072; max.
• Outputs
131 072; max.
Analog channels
• Inputs
8 192; max.
