Synchronization modules
14.1 Synchronization modules for the CPU 410.
CPU 410 Process Automation/CPU 410 SMART
242 System Manual, 05/2017, A5E31622160-AC
5. Repeat steps 1 to 4 for the second synchronization module.
6. Repeat the process for the second fault-tolerant CPU.
Connect the IF1 interface of the first CPU with the IF1 interface of the second CPU and
the IF2 interface of the first CPU with the IF2 interface of the second CPU.
Note
Wiring synchronization modules crosswise
If you wire synchronization modules crosswise, i.e. the IF1 interface of the first CPU with
the IF2 interface of
the second CPU and vice versa, the two CPUs take over the master
role and the system will now function properly. The LEDs IFM 1 and IFM 2 are lit on both
CPUs.
Make sure that you connect the IF1 interface of the first CPU with the IF1 interface of the
sec
ond CPU and the IF2 interface of the first CPU with the IF2 interface of the second
Removing the synchronization module
1. Slightly press the release of the fiber-optic cable and remove it from the synchronization
module.
2. Fold the clip of the synchronization module to the front and remove the synchronization
module from the fault-tolerant CPU interface.
3. Place the dummy plug on the synchronization module.
4. Repeat this procedure for all interfaces and both fault-tolerant CPUs.
Maximum distance between the
10 m 10 km
3.3 V, supplied by the CPU
3.3 V, supplied by the CPU
Power loss
Wavelength of the optical
0.77 W
850 nm
0.83 W
1310 nm
Maximal permitted attenuation of the
7.5 dB 9.5 dB
Maximum permitted difference in
9 m 50 m
Dimensions W x H x D (mm)
