14.1 Mechanical Installation
Step Procedure
1 Push
the enclosed gasket from the rear over the housing and
insert the OP from the front in the prepared mounting cutout.
T
ake suitable measures to prevent the OP from falling out of the
front panel before it is finally fixed in position.
2
Insert the retaining hooks of the screw type clamps
enclosed with the OP into the corresponding mounting locations
in the housing of the OP
.
Y
ou require four screw type clamps for the OP7 and five for the
OP17.
3 T
ighten the OP from behind in the front panel using a screw
-
driver
.
Note:
Make sure that the gasket fits properly on the front
plate. A
void excessively high torques.
Front panel
OP17
OP7
Installing
the OP
