5-4
Equipment Manual OP7, OP17
Release 04/99
5.3 Editing Screens
Screens can be manipulated, i.e. edited, by means of entries in input fields
and combined I/O fields. T o edit a screen, proceed as follows:
Step Procedure
1 Select the screen you wish to edit as described in section 5.2.
The cursor jumps to the first input field.
2
Move the cursor to the field concerned.
3 Perform the modifications you wish to make as described in sec -
tion 3.2.
4 After confirming your input, position the cursor again, if neces -
sary
, to perform further modifications.
5 T erminate editing
ESC
5.4 Printing Screens
To output a screen to a connected printer , proceed as follows:
Step Procedure
1 Select the screen you want to edit as described in section 5.2.
The screen directory is displayed (but not when selecting by
means of a function key or a PLC job; in these instances, the
corresponding screen is printed immediately).
2 Scroll to the screen number you require or , if
configured, to the screen title
3 Print the screen selected
ENTER
4 T erminate the action
ESC
Procedure
Procedure
