C-1
Equipment Manual OP7, OP17
Release 04/99
Technical Data
OP7 OP17
Housing
PP DP DP-12 PP DP DP-12
Overall dimensions W x H
x D
144 mm x 180 mm x 42.5 mm 240 mm x 204 mm x 54 mm
Mounting cutout B x H 135 mm x 171 mm 231 mm x 195 mm
Mounting depth 38.5 mm 50 mm
Degree of protection
– front
– rear
IP65
IP20
Weight approx. 0.430 kg 0.960 kg
OP7 OP17
Memory
PP DP DP-12 PP DP DP-12
Flash memory for
configuration data
and data records
128 kbytes 256 kbytes
OP7 OP17
Display
PP DP DP-12 PP DP DP-12
Type LCD with LED backlighting
Number of lines 4 4 or 8 (configurable)
Characters per line 20 20 or 40 (depending on number of lines)
Font size 8 mm 11 mm or 6 mm
(depending on number of lines)
