15-6
Equipment Manual OP7, OP17
Release 04/99
15.4 Testing the Configuration in OFFLINE Mode
In OFFLINE mode, you can test the dif ferent functions and the configura -
tions downloaded from the PC or PU independently of the PLC.
In OFFLINE mode, tags are not updated.
Step Procedure
1 Switch the OP to OFFLINE mode using the standard screen
System settings ! OPMode.
2 Check all configured screens for proper display .
3 Check the screen hierarchy .
4 Check the input fields.
5 T est the soft keys.
6 Check the dif ferent items of message text.
7 T est the function keys.
If errors occur when you perform the tests, you must download the configura -
tion again.
Purpose
Procedure
End of test
