16-1
Equipment
Manual OP7, OP17
Release 04/99
Device Description
This
chapter describes the versions, dimension drawings and connection
elements of Operator Panels OP7 and OP17.
16.1 OP7

134
170
180
 
 
 
144

116,5
The
OP7 requires the following mounting cutout (WxH):
135
+1
mm x 171
+1
mm.
In this chapter
Dimensions
Mounting cutout
16
