9-2
Equipment Manual OP7, OP17
Release 04/99
9.1 FORCE VAR
You call FORCE V AR by means of the standard screen ForceVAR . Following
the call, the operand list is displayed. Depending on the display , an operand is
displayed on either one or two lines.
Figure 9-1 shows the display for the SIMA TIC S5 on the OP17 (8 x 40 repre -
sentation). Figure 9-2 shows the display for the SIMA TIC S7/M7 on the OP7.
DB34 ADR122 KM = 00010010 00110100
T 1 KT = 3.4 s
Value field
Format field
Numbers field
Operand field
*
Updating in progress
Figure 9-1 Display of PLC Operands for SIMATIC S5 (OP17, 8x40 representation)
DB34 ADRxx *
INT = 999
Operand field
Format field Value field
Updating in progress
Figure 9-2 Display of PLC Operands for SIMATIC S7/M7 (4x20 representation)
