S7-200 Programmable Controller, CPU 210
C79000-G7076-C235-01
A.2 CPU 210 DC Power Supply, 24 VDC Inputs, 24 VDC Outputs
Model Number: 6ES7 210-0AA00-0XB0
General Features
Physical Size (L x W x D) 90 x 80 x 62 mm
(3.54 x 3.15 x 2.44 in.)
Weight 0.18 kg (0.4 lbs.)
Power Dissipation 10 W maximum, with
maximum output loading
User Program Size 256 words (EEPROM)
I/O 4 Inputs / 4 Outputs
Boolean Execution Speed 95 µs per instruction
Internal Memory Bits 48 bits
Timers 4
Counters 4 (retentive)
Analog Adjustments 1
Standards Compliance UL 508 CSA C22.2 142
FM Class I, Division 2
VDE 0160 compliant
CE compliant
Output Points
Output Type Sourcing Transistor
Voltage Range 20.4 to 28.8 VDC
Maximum Load Current*
per single point
all points total
Linear derate 40° to 55° C
0° to 40° C 55° C
0.75 A 0.50 A
2.25 A 1.75 A
Inductive Load Clamping
single pulse
repetitive
(per common)
2A L/R = 10 ms
1A L/R = 100 ms
1 W energy dissipation
(1/2 Li
2
x switch rate t 1 W)
Leakage Current 100 µA
Switching Delay 25 µs on, 120 µs off
Surge Current 4 A, 100 ms
Voltage Drop 1.8 V maximum at maximum
current
Optical Isolation 500 VAC, 1 minute
Short Circuit Protection None
Input Points
Input Type (IEC 1131-2) Sink/Source
IEC 1131 Type 1 in Sink
mode
ON State Range 15-30 VDC, 4 mA minimum
35 VDC, 500 ms surge
ON State Nominal 24 VDC, 7 mA
OFF State Maximum 5 VDC, 1 mA
Response Time
I0.0 to I0.3
Interrupt I0.0
15 ms maximum
20 s on, 40 s off
Optical Isolation 500 VAC, 1 minute
Power Supply
Voltage Range 20.4 to 28.8 VDC
Input Current 25 mA at 24 V typical
150 mA at 24 V maximum
load
UL / CSA Rating 5 VA
Hold Up Time 20 ms minimum from loss of
24 VDC power
Inrush Current 10 A peak at 28.8 VDC
5 VDC Current 100 mA
Isolated No
DC Sensor Supply
Voltage Range 16.4 to 28.8 VDC
Ripple/Noise (<10Mhz) Same as supplied voltage
24 VDC Available Current 100 mA
Short Circuit Current Limit < 120 mA
Isolated No
