A-8
S7-200 Programmable Controller, CPU 210
C79000-G7076-C235-01
A.4 CPU 210 AC Power Supply, AC Inputs, Relay Outputs
Model Number: 6ES7 210-0CA00-0XB0
General Features
Physical Size (L x W x D) 90 x 80 x 62 mm
(3.54 x 3.15 x 2.44 in.)
Weight 0.23 kg (0.51 lbs.)
Power Dissipation 5.0 W maximum, with
maximum output loading
User Program Size 256 words (EEPROM)
I/O 4 Inputs / 4 Outputs
Boolean Execution Speed 95 µs per instruction
Internal Memory Bits 48 bits
Timers 4
Counters 4 (retentive)
Analog Adjustments 1
Standards Compliance UL 508 CSA C22.2 142
FM Class I, Division 2
CE compliant
Output Points
Output Type Relay, dry contact
Voltage Range 5 to 30 VDC / 250 VAC
Maximum Load Current
per point
per common
2 A
4 A
Overcurrent Surge 7 A with contacts closed
Isolation Resistance 100 MW minimum (new)
Switching Delay 10 ms maximum
Lifetime 10,000,000 Mechanical
100,000 with Rated Load
Contact Resistance 200 mW maximum (new)
Isolation
coil to contact
contact to contact
1500 VAC, 1 minute
1000 VAC, 1 minute
Short Circuit Protection None
Input Points
Input Type (IEC 1131-2) Type 1 Sinking
ON State Range 164 to 265 VAC, 47 to 63 Hz,
4 mA minimum
ON State Nominal 230 VAC, 50 Hz, 7 mA
OFF State Maximum 40 VAC, 1 mA
Response Time 40 ms typical
55 ms maximum
Optical Isolation 1500 VAC, 1 minute
Power Supply
Voltage / Frequency Range 85 to 264 VAC at 47 to 63 Hz
Input Current 1.74 VA typical, no load
4.75 VA typical, maximum
load
Hold Up Time 20 ms minimum from loss of
AC power
Inrush Current 10 A peak at 265 VAC
Fusing (non-replaceable) 2 A, 250 V, Slow Blow
Isolated Yes. Transformer, 1500 VAC,
1 minute
DC Sensor Supply
Not applicable
CPU 210 Data Sheets
