2.5.2
Technical data - servo motors
General technical data
Parameter
Description
Type of motor
Permanent-magnet synchronous motor
Cooling
Self-cooled
Relative humidity [RH]
90% (non-condensing at 30°C )
Installation altitude [m]
≤ 1000 (without power derating)
Thermal class
B
Vibration severity grade A (according to IEC 60034-14)
Shock resistance [m/s
2
]
25 (continuous in axial direction); 50 (continuous in radial direction); 250
(in a short time of 6 ms)
Bearing lifetime [h]
> 20000
1)
Paint finish
Black
Protection degree of shaft
IP 65, with shaft oil seal
Type of construction
IM B5, IM V1, and IM V3
Positive rotation
Clockwise (default setting in servo drives)
Certification
CE, EAC
1)
This lifetime is only for reference. When a motor keeps running at rated speed under rated load, replace its bearing after
20,000 to 30,000 hours of service time. Even if the time is not reached, the bearing must be replaced when unusual
noise, vibration, or faults are found.
Specific technical data
SIMOTICS S-1FL6, low inertia servo motor
Article No.
1FL60...
22
24
32
34
42
44
52
54
Rated power [kW]
0.05
0.1
0.2
0.4
0.75
1
1.5
2
Rated torque [Nm]
0.16
0.32
0.64
1.27
2.39
3.18
4.78
6.37
Maximum torque [Nm]
0.48
0.96
1.91
3.82
7.2
9.54
14.3
19.1
Rated speed [rpm]
3000
Maximum speed [rpm]
5000
Rated frequency [Hz]
200
Rated current [A]
1.2
1.2
1.4
2.6
4.7
6.3
10.6
11.6
Maximum current [A]
3.6
3.6
4.2
7.8
14.2
18.9
31.8
34.8
Moment of inertia [10
-4
kgm
2
]
0.031 0.052 0.214 0.351 0.897 1.15 2.04 2.62
Moment of inertia (with
brake) [10
-4
kgm
2
]
0.038 0.059 0.245 0.381 1.06 1.31 2.24 2.82
Recommended load to mo-
tor inertia ratio
Max. 30x Max. 20x Max. 15x
Operating temperature [°C] 1FL602❑, 1FL603❑ and 1FL604❑: 0 to 40 (without power derating)
1FL605❑: 0 to 30 (without power derating)
1)
Storage temperature [°C] -20 to +65
Maximum noise level [dB]
60
