Parameter assignment / addressing
5.2 Creating a project and configuring the communication
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
117
A PROFIBUS subnet with factory settings (1.5 Mbit/s transmission rate) is created
automatically.
The PG/PC is now connected to the SIMOTION D4x5-2 via PROFIBUS. You can configure
and parameterize your system.
Note
If you do not use the factory settings, you must configure the PROFIBUS interfaces in HW
Config. Please make sure that the S7 online access has been activated (PG/PC connection
must be yellow and bold in NetPro).
Inserting a further SIMOTION device
If you insert a further SIMOTION device using "Insert SIMOTION device", the PG/PC
interface selection dialog box is not displayed. A further SIMOTION device is automatically
connected to the PG/PC via PROFIBUS and a new unique IP address (address 4, 5, etc.
until 125 is reached) is calculated.
Additional references
Further information on the topic of "Going online" can be found:
● In the online help via the "Contents" tab at
– "Diagnostics" > "Overview of service and diagnostics options" > "Part III" > "Go online"
– "Insert device and connect to target system" > "Go online/offline"
● On the Internet at (http://support.automation.siemens.com/WW/view/en/22016709
)
● In SIMOTION Utilities & Applications, FAQ "Online connections to SIMOTION devices"
SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
See also
Establishing a PG/PC assignment (Page 130)
5.2.3 Configuring the Ethernet PG/PC interface
Requirement
The following requirements must be satisfied in order to configure the PG/PC interface:
● You have completed the "Insert SIMOTION Device" dialog box with "OK".
● A PG/PC has not yet been configured in the project.
If these requirements have been satisfied, you can configure the interface for the PG/PC
connection in the "Interface Selection - D4x5" dialog box.
