Page #43 background image
Connecting
3.2 Safety information for wiring
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
43
3.2 Safety information for wiring
Requirement
You have mounted the Control Unit in the control cabinet.
The SIMOTION D4x5-2 Control Unit has a connection for the protective conductor and a
connection for the equipotential bonding conductor (M5 screw, Torx T25). Only one
connection is available for the CX32-2 - this must be used both for the protective conductor
and the equipotential bonding conductor.
Note
Requirements for functional safety for machines and systems; reliability and EMC are only
guaranteed with original SIEMENS cables.
Note the following safety information:
DANGER
De-energize the system/machine before you wire the Control Unit.
Protective conductor connection
SIMOTION D and the SINAMICS S120 drive system are designed for use in cabinets with a
protective conductor connection.
All system components and machine parts must be incorporated in the protection concept.
The drive line-up must be arranged on a common bright mounting plate
in order to
comply with the EMC limit values. The connection
establishes a low-impedance
connection to the mounting plate.
The mounting plate must be connected to the protective conductor connection of the control
cabinet. For this purpose, a connection
must be established to the protective conductor
bar
. The protective conductor bar must be connected to the protective conductor .
The protective connection (PE connection) that is used for the motors
must be
established through the motor cable.
For EMC reasons, the motor cable shield must be laid flat at both the Motor Module (MM) /
Power Module (PM) and motor.
A protective connection
must also be established for components that are not connected
with low impedance (e.g. control cabinet door via hinges
).
Example: Booksize axis grouping comprising Control Unit (CU), line module (LM) and motor
modules (MM) as well as drive in blocksize format comprising a power module (PM) with
snapped on Control Unit (CU)
