SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
373
Configuration of drive-related I/Os (without symbolic
assignment)
A
A.1 Overview
The configuration of local measuring inputs is fundamentally different to the configuration of
global measuring inputs.
The assignment of the local measuring inputs is permanently related to the hardware of the
control unit and is performed
● On the drive side via the drive expert list and
● During the configuration of the TO measuringInput via the measuring input number.
Local and global measuring inputs have different properties. Detailed information on the
differences can be found in the appendix,
- in Section Local and global measuring inputs (Page 374).
Information a
bout the configuration can be found
● For global measuring inputs (with symbolic assignment) in Section Configuration of global
measuri
ng inputs (Page 262).
● For lo
cal measuring inputs in the appendix, in Section Configuration of local measuring
inputs (P
age 376)
Additional references
Further information and programming examples for configuring drive-related I/Os without
symbolic assignment can be found
● At the following Internet address
(http://support.automation.siemens.
com/WW/view/en/29063656)
● In SIMOTION Utilities & Applications
SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
