Siemens SINUMERIK 808D ADVANCED Parameter Manual

4: ACP approach position from the positive direction.
5: ACN approach position from the negative direction.
43300 ASSIGN_FEED_PER_REV_SOURCE - V1, P2, S1
- Revolutional feedrate for positioning axes/spindles DWORD Immediately
CTEQ
- - 0 -3 31 1/1 M
Description: 0= No revolutional feedrate is active.
>0= Machine axis index of the rotary axis/spindle, from which the revolutional
feedrate is derived.
-1= The revolutional feedrate is derived from the master spindle of the channel in
which the axis/spindle is active
-3= The revolutional feedrate is derived from the master spindle of the channel in
which the axis/spindle is active. No revolutional feedrate is active if the master
spindle is at a standstill.
Related to ....
SD42600 $SC_JOG_FEED_PER_REV_SOURCE (revolutional feedrate for geometry axes on
which a frame with rotation acts in JOG mode.)
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43320 JOG_POSITION - -
mm, degrees JOG position DOUBLE Immediately
-
- - 0.0 - - 7/7 U
Description: Position to be approached in JOG. Depending on MD10735 $MN_JOG_MODE_MASK bit 4 axial
frames and, with an axis configured as geometry axis, the tool length offset are
considered.
43340 EXTERN_REF_POSITION_G30_1 , A12 FBFA
- Reference point position for G30.1 DOUBLE Immediately
-
- - 0.0 - - 7/7 U
Description: Reference point position for G30.1.
This setting data will be evaluated in CYCLE328.
43400 WORKAREA_PLUS_ENABLE - A3
- Working area limitation active in positive direction BOOLEAN Immediately
CTEQ
- - FALSE 0 - 7/7 U
Description: 1: The working area limitation of the axis concerned is active in the positive
direction.
0: The working area limitation of the axis concerned is switched off in the positive
direction.
The setting data is parameterized via the operator panel in the operating area
"Parameters" by activating/deactivating the working area limitation.
SD irrelevant for ......
G code: WALIMOF
NC setting data
Parameter Manual
Parameter Manual, 08/2015, 6FC5397-8EP40-0BA1 345
