Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
1-1
Flexible NC programming
1
1.1 1.1 Variables and arithmetic parameters (user-defined variables,
arithmetic parameters, system variables)
Function
Using variables in place of constant values makes a program more flexible. You can respond
to signals such as measured values or, by storing setpoints in the variables, you can use the
same program for different geometries.
With variable calculation and jump instructions a skilled programmer is able to create a very
flexible program archive and save a lot of programming work.
Variable types
The control uses 3 classes of variable:
User-defined variables Name and type of variable defined by the user, e.g., arithmetic
parameter.
Arithmetic variables Special, predefined arithmetic variable whose address is R plus a
number. The predefined arithmetic variables are of the REAL type.
System variables Variable provided by the control that can be processed in the
program (write, read). System variables provide access to zero
offsets, tool offsets, actual values, measured values on the axes,
control states, etc.
(See Appendix for the meaning of the system variables).
Variable types
Type Meaning Value range
INT Integers with leading sign ±(2
31
- 1)
REAL Real numbers (fractions with decimal
point, LONG REAL in acc. with IEEE)
±(10
-300
… 10
+300
)
