User stock removal programs
14.2 Contour preparation (CONTPRON)
Job planning
14-2 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
Parameters
CONTDCON Activate tabular contour decoding (6 columns)
CONTPRON Activate tabular contour preparation (11 columns)
INTERSEC Calculate the intersection of two contour elements.
(Only for tables created by CONTPRON).
ISPOINTS Calculate the possible intersections of two contour elements.
(Only for tables created by CONTPRON).
EXECTAB Non-modal processing of the contour elements of a table
(Only for tables created by CONTPRON).
CALCDAT Calculate the radiuses and centers of a circle that consists of 3
or 4 points.
EXECUTE Terminate contour preparation
ERROR Variable for error checkback, type INT
1 = error; 0 = no error
EXECUTE deactivates the contour preparation and switches back to the normal execution
mode.
Example:
N30 CONTPRON(...)
N40 G1 X... Z...
N50 ...
N100 EXECUTE(...)
14.2 14.2 Contour preparation (CONTPRON)
Function
The blocks executed after CONTPRON describe the contour to be prepared. The blocks are
not processed but are filed in the contour table. Each contour element corresponds to one
row in the two-dimensional array of the contour table. The number of relief cuts is returned.
Programming
CONTPRON (TABNAME, MACH, NN, MODE)
Deactivate contour preparations and at the same time switch back to the normal execution
mode:
EXECUTE (ERROR)
