Tool offsets
8.4 Keep tool radius compensation constant (CUTCONON)
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
8-13
8.4 8.4 Keep tool radius compensation constant (CUTCONON)
Function
The "Keep tool radius compensation constant" function is used to suppress the tool radius
compensation for a number of blocks, whereby a difference between the programmed and
the actual tool center path traveled set up by the tool radius compensation in the previous
blocks is retained as the offset. It can be an advantage to use this method when several
traversing blocks are required during line milling in the reversal points, but the contours
produced by the tool radius compensation (follow strategies) are not wanted. It can be used
independently of the type of tool radius compensation (2
1
/
2
D, 3D face milling, 3D
circumferential milling).
Programming
CUTCONON
CUTCONOF
Parameters
CUTCONON Activate the tool radius compensation constant function
CUTCONOF Deactivate the constant function (default setting)
Example
N10 ;Definition of tool d1
N20 $TC_DP1[1,1] = 110 ;Type
N30 $TC_DP6[1,1]= 10. ;Radius
N40
N50 X0 Y0 Z0 G1 G17 T1 D1 F10000
N60
N70 X20 G42 NORM
N80 X30
N90 Y20
N100 X10 CUTCONON ;Activate compensation suppression
N110 Y30 KONT ;Insert bypass circle if necessary on
;deactivation of contour suppression
N120 X-10 CUTCONOF
N130 Y20 NORM ;No bypass circle on deactivation of TRC
N140 X0 Y0 G40
N150 M30
