5 Measuring Cycles for Milling Machines and Machining Centres 08.96
5.3.1 L979 Measure hole (at random angles)
5.3.1 L979 Measure hole (at random angles)
The following parameters must be defined prior to call:
Parameters Description
R08 Extended T address (see Section 2.2)
R09 T number (tool number) (see Section 2.2)
R10 = 0
> 0
No automatic tool offset
Automatic tool offset (see Section 2.2)
R11 = 0
> 0
Without empirical and average value
Empirical value memory number (average value memory for diameter)
(see Section 2.3)
R13 = 0...359.5
R13 = 0/-360
Compensation angle position for monodirectional probe (see
Section 2.5)
Positioning direction of spindle with multidirectional probe and MDC
7004.0=1
R20 Centre point abscissa (in relation to workpiece zero point)
R21 Centre point ordinate (in relation to workpiece zero point)
R22 Number of measuring points/probe type/probe number
R23 = 1 Measure hole
R24 = 0...360 Start angle (with reference to abscissa (horizontal axis))
R25
R25 = 0
Variable measuring speed in mm/min
Standard cycle value
R26 = 0...360 Indexing angle
R27 = 1...R
max
Number of measurements at same location (typically 1..3)
R28 = 1...R
max
Multiplication factor for measurement path ”2a”
R29 = 1...R
max
Weighting factor k for averaging (typically 1...3)
R31 Velocity for circular interpolation
R33 Zero offset range
R34 Compensation range with averaging
R36 Safe area
R37 Dimensional difference check
R40 Upper tolerance limit (according to drawing)
R41 Lower tolerance limit (according to drawing )
R42 Set value diameter (according to drawing)
See Section 10.2 for result display parameters.
