01.93 10 Lists
10.2 Result displays
10.2 Result displays
The function of the result displays depends on the
machine configuration.
(see machine tool manufacturer's specifications)
Result displays are available for displaying the measurement results. These displays are auto-
matically shown on the screen on completion of the cycle.
The numbers in the fields of the displays shown indicate the R parameter in which the relevant
data must be entered.
Measurement result display for tool measurement
AUTOMATIC - CH1
Tool measurement: Measurement result Cycle 215
Input data
Measurement variant 23
D memory No. 212
Tool type 216
EV memory No. 213
Empirical value 214
Safe area 36
Perm. dim. diff'ce 37
Probe No. 218
Data 217
Output data
Measure (calibrate) Actual value Difference
L1 1.5 (Abscissa - R.) 200 201
L2 1.5 (Abscissa +R.) 202 203
D/R 1.5 (Ordinate - R.) 204 205
L1 2.5 (Ordinate +R.) 206 207
L2 2.5 (Applicate - R.) 208 209
D/R 2.5 (Applicate +R.) 210 211
Alarm No. 219
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 10–21
SINUMERIK 840/850/880 (BN)
