3.2.11 L971 Auxiliary cycle for tool measuring cycles (internal)
3.2.11 L971 Auxiliary cycle for tool measuring cycles (internal)
This cycle must be available in the part program memory or in the UMS for tool measurement.
3.2.12 L980 Auxiliary cycle for tool measuring cycle L981 (internal)
This cycle must be available in the part program memory or in the UMS when using measuring
cycle L981 (searching for a hole/slot).
3.2.13 L988 Auxiliary cycle for workpiece measuring cycles
(internal/external)
This function can be set via MDC.
(See machine tool manufacturers specifications)
Measurement results obtained by the use of workpiece measuring cycles can be logged using
the cycle L988 and the subfunction FB package ”Logging of measurement results”.
3.2.14 L989 Auxiliary cycle for workpiece measuring cycle L979
*)
This cycle must be available either in the part program memory or in the UMS when using the
workpiece measuring cycle L979.
END OF SECTION
_______
*) Version 3.0 and higher
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 3–9
SINUMERIK 840/850/880 (BN)
